Cockpit Cable Harness for 2007 Mercedes-Benz R320

Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED. SEE WIS FOR REPAIR INSTRUCTIONS. ================================================================================================= SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION: A 001 546 99 41 GREEN 0.7 - 2.4 MM2 A 002 546 00 41 RED 2.0 - 4.0 MM2 A 002 546 01 41 BLUE 3.5 - 8.0 MM2 A 002 546 11 41 YELLOW 7.5 - 12.0 MM2 BUTT JOINT: A 002 546 13 41 0.5 MM2 A 002 546 14 41 0.8 MM2 A 002 546 15 41 1.3 MM2 A 002 546 16 41 2.0 MM2 ===================================================================================================

Description: FUSE BOX 0.35--1.0 MM2. 1.0 MM2 GSK1
Leitungsquerschnitt Min/Max: 1,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.

MSRP $2.70

$2.00

MSRP $2.70

$2.00

110

Contact Spring

008-545-82-26-64

Mercedes-Benz

Description: 0.35-1.5 mm. 0.35-1.0 mm2, 1polig.

MSRP $4.50

$3.38

MSRP $4.50

$3.38

110

Electrical Wiring Harness

000-540-51-05

Mercedes-Benz

Notes: NO LONGER AVAILABLE
CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED. SEE WIS FOR REPAIR INSTRUCTIONS. ================================================================================================= SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION: A 001 546 99 41 GREEN 0.7 - 2.4 MM2 A 002 546 00 41 RED 2.0 - 4.0 MM2 A 002 546 01 41 BLUE 3.5 - 8.0 MM2 A 002 546 11 41 YELLOW 7.5 - 12.0 MM2 BUTT JOINT: A 002 546 13 41 0.5 MM2 A 002 546 14 41 0.8 MM2 A 002 546 15 41 1.3 MM2 A 002 546 16 41 2.0 MM2 ===================================================================================================

Description: REAR FUSE BOX 1,5-2,5 MM2. 1.5 MM2 GSK1
Leitungsquerschnitt Min/Max: 1,5mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.

View Details

115

Plug

044-545-16-28

Mercedes-Benz

Description: Connector, interior/engine black x25/2*2. 6-pin mcp2.8. Cockpit/interior plug connector x18. 6-pin mcp2.8. Connector, cockpit/interior, black x18. 6-pin mcp2.8. Engine compartment/interior connector x25/2. 6-pin mcp2.8.

MSRP $7.00

$5.13

MSRP $7.00

$5.13

120

Male Spade Connector

000-540-49-15

Mercedes-Benz

Description: 0.2-0.5 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 0,2-0,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.

MSRP $3.40

$2.50

MSRP $3.40

$2.50

120

Male Spade Connector

035-545-25-28

Mercedes-Benz

Description: 1.5-2.5 MM2 MCP2.8
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: MCP
Model 2: 2.8.

MSRP $2.50

$1.88

MSRP $2.50

$1.88

125

305452828 - Electrical Equipment and Instruments: Plug for Mercedes-Benz Image

Inst Panel Speaker Connector

030-545-28-28

Mercedes-Benz

MSRP $1.70

$1.25

MSRP $1.70

$1.25

130

Contact Socket

016-545-41-26

Mercedes-Benz

MSRP $5.50

$4.13

MSRP $5.50

$4.13

135

Receptacle Housing

002-546-79-40

Mercedes-Benz

Description: Can b voltage distributor x30/4. 22-pin.

MSRP $4.50

$3.38

MSRP $4.50

$3.38

150

Plug Housing, Rectangular

049-545-00-28

Mercedes-Benz

Description: Front center bracket separation point x138/1*1. 10-pin mqs. Overhead control panel/ffs connector x25/8. 10-pin mqs. Separation point rear panel door x8/45*1. 10-pin mqs. Connector, center nozzle x122/1. 10-pin mqs.

View Details

155

Crimp Tml Pin Contact

032-545-39-28

Mercedes-Benz

Description: X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...

MSRP $2.80

$2.06

MSRP $2.80

$2.06

160

Plug

042-545-92-28

Mercedes-Benz

MSRP $4.00

$3.00

MSRP $4.00

$3.00

170

Receptacle Housing

094-545-36-01

Mercedes-Benz

Description: Plug socket 12v. Pass. Left rear reading lamp. 2-pin ff6.3model 1: ffmodel 2: 6.3slots: 2. Additional heater control unit. 2-pin ff6.3model 1: ffmodel 2: 6.3slots: 2. Radio connection x58/2. 2-pin ff6.3model 1: ffmodel 2: 6.3slots: 2. Front interior socket ...

MSRP $5.25

$3.88

MSRP $5.25

$3.88

175

Receptacle

000-540-45-15

Mercedes-Benz

Description: Tin-plated. 1.5-2.5 MM2 FF6.3Leitungsquerschnitt Min/Max: 1,0-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: FFModel 2: 6.3. TO 001 545 10 28,012 545 31 28. 1.5-2.5 MM2 FF6.3Leitungsquerschnitt Min/Max: 1,0-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: ...

MSRP $2.70

$2.00

MSRP $2.70

$2.00

240

Distributor

003-546-42-40

Mercedes-Benz

Description: Can bus distributor x30/5. 12x2/1x3 pin. Potential distributor can c x63/4. 12x2/1x3 pin. Can bus c, right x30/19. 12x2/1x3 pin. Can c connector x63/4. 12x2/1x3 pin. Connector can databus x63/4,. 12x2/1x3 pin. Can bus c, left x30/5. 12x2/1x3 pin. Can bus c x30/18. 12x2/1x3 pin. Can bus c, left x63/4. 12x2/1x3 pin. Voltage distributor, can bus 27-pin. 12x2/1x3 pin.

MSRP $37.00

$27.50

MSRP $37.00

$27.50

300

Wiring Harness

251-540-02-06

Mercedes-Benz

Description: Steering column electrically adjustable x4/39-m20/1+2. On steering column jacket tube.

View Details

400

Electric Line
