4MATIC® Steering Knuckle and Transverse Control Arm for 2015 Mercedes-Benz C400
No.
Part # / Description / Price
Price
10
MSRP $560.00
$417.50
10
MSRP $555.00
$415.00
20
Wheel Bearing
Mercedes-Benz
Mercedes-Benz Description: At left with wheel flange. Left front.
MSRP $364.00
$272.50
MSRP $364.00
$272.50
30
Hexalobular Head Screw Mercedes-Benz
Mercedes-Benz Description: M12X57,5
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. To left steering knuckle, front axle. Wheel bearing left rear. Drive shaft to front wheel hub, left. Wheel bearing to steering knuckle at left M12X57,5.
Diameter: 12mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. To left steering knuckle, front axle. Wheel bearing left rear. Drive shaft to front wheel hub, left. Wheel bearing to steering knuckle at left M12X57,5.
MSRP $6.50
$4.88
MSRP $6.50
$4.88
50
Hexalobular Head Screw Mercedes-Benz
Mercedes-Benz Description: M16X60
Diameter: 16mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Propeller shaft to flange. Propeller shaft to front wheel hub, left. Drive shaft to flange. Drive shaft to front wheel hub. Left axle shaft.
Diameter: 16mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Propeller shaft to flange. Propeller shaft to front wheel hub, left. Drive shaft to flange. Drive shaft to front wheel hub. Left axle shaft.
MSRP $24.50
$18.13
MSRP $24.50
$18.13
100
MSRP $795.00
$593.75
100
MSRP $815.00
$610.00
120
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: M10X95
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Transverse control arm to body at left.
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Transverse control arm to body at left.
MSRP $11.00
$8.13
MSRP $11.00
$8.13
120
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: M10X90
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Starter position without starter. Transmission to engine. Starter mount. Starter fastening. Transmission case to crankcase. Starting motor to crankcase. Heat shield mounting. Motor to gearing.
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Starter position without starter. Transmission to engine. Starter mount. Starter fastening. Transmission case to crankcase. Starting motor to crankcase. Heat shield mounting. Motor to gearing.
140
Hex Nut W Flange + Piece Mercedes-Benz
Mercedes-Benz Description: M14X1,5
Diameter: 14mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm. Arm to steer. Knuck. Transverse control arm to left body. Nut, ball joint, transverse control arm, left, upper, front axle.
Diameter: 14mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm. Arm to steer. Knuck. Transverse control arm to left body. Nut, ball joint, transverse control arm, left, upper, front axle.
MSRP $3.70
$2.75
MSRP $3.70
$2.75
200
MSRP $545.00
$407.50
200
MSRP $404.00
$302.50
210
Bearing Element, Elastom Mercedes-Benz
Mercedes-Benz Description: Left, adjustable bearing. At left, adjustment bearing.
MSRP $142.00
$106.25
MSRP $142.00
$106.25
220
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: M14X1,5X125
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Left spring link to integral carrier. Torque strut to integral carrier, left. Spring link left to frame-type integral support.
Diameter: 14mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm. Left spring link to integral carrier. Torque strut to integral carrier, left. Spring link left to frame-type integral support.
MSRP $34.50
$25.63
MSRP $34.50
$25.63
230
Washer, Plane Parallel Mercedes-Benz
Mercedes-Benz Description: Spring link to integral carrier, left.
MSRP $4.50
$3.38
MSRP $4.50
$3.38
240
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: M14X1.5
Diameter: 14mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Width across flats: 21mm. Strut rod to integral carrier. Cross strut to integral carrier. Transverse control arm to left steering knuckle. Torque strut to frame-type int. Supp.. Lower transverse control arm to left wheel carrier.
Diameter: 14mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Width across flats: 21mm. Strut rod to integral carrier. Cross strut to integral carrier. Transverse control arm to left steering knuckle. Torque strut to frame-type int. Supp.. Lower transverse control arm to left wheel carrier.
MSRP $7.00
$5.13
MSRP $7.00
$5.13
240
MSRP $8.00
$6.00
270
Nut With Clamping Piece Mercedes-Benz
Mercedes-Benz Description: Lower control arm to steering knuckle, left. M16. Transverse control arm at left wheel carrier.
MSRP $9.75
$7.19
MSRP $9.75
$7.19
300
MSRP $350.00
$261.25
300
MSRP $420.00
$315.00
300
MSRP $390.00
$291.25
300
MSRP $420.00
$315.00
310
Bearing Element, Elastom Mercedes-Benz
Mercedes-Benz Notes: NEGATIVE CHANGE IN CASTER ( - 3 MM )
Description: Tension rod left.
310
Bearing Element, Elastom Mercedes-Benz
Mercedes-Benz Notes: POSITIVE CHANGE IN CASTER ( + 3 MM )
Description: Tension rod left.
MSRP $142.00
$106.25
MSRP $142.00
$106.25
